Welded Npauj Npaim Valve Specification
1. Loj: 2 "~ 42" (DN 50 ~ DN 1050)
2. Siab: Chav Kawm 150 ~ Chav Kawm 2500, PN 16 ~ PN 420
3. Xaus kev sib txuas: Welded
Cov ntaub ntawv tseem ceeb
Casting hlau: WCB, WCC, WC6, WC9, LCB, LCC, CF8, CF3, CF8M, CF3M, CF8C, 4A, 5A, 6A, CN7M, CW6MC,
CW12MW,CU5MCuC,C5,C12,M35-1
Tshwj xeeb Alloy Steel: Inconel, Hastelloy, Monel, Incoloy 825
Welded Npauj Npaim Valve Standard thiab Nta
Txheem:
1. Tus Qauv Tsim: API 609 / ASME B16.34
2. Lub ntsej muag rau ntsej muag: ASME B16.10 / API 609
3. Xaus Flange: ASME B16.5 / ASME B16.47
4. Butt welded xaus: ASME B16.25
5. Kev Tshawb Fawb & Kev Ntsuas: API 598
Nta:
1. Nws yog tsim thiab tsim nrog ib tug tshiab structural daim ntawv ntawm welding midline disc phaj thiab luv luv structural steel phaj. ntawm high-temperature expansion thiab kev ua haujlwm yooj yim
2. Txhim khu kev sib khi, kev ua haujlwm yooj yim, qhib thiab kaw nrawm.
3. Hom valve no uas tsis muaj flange, uas ua rau cov yeeb nkab elegantly thiab khi li yooj yim
4. Nws txais yuav triple offset elasticity los yog ntau txheej txheej nyuaj sealing configuration, lub peev xwm hermetical tuaj yeem ncav cuag kev ua tau zoo sealing.
5. Lub sealing ntawm disc tuaj yeem hloov tau los ntawm loosening lub nplhaib disc, txuag tus nqi ntawm lub valve.
6. Qhov kawg ntawm lub valve inlet chaw nres nkoj thiab qhov hluav taws xob qhov chaw nres nkoj muaj lub annular tus thawj coj, uas yog conducive rau lub valve thiab yeeb nkab vuam kub nqus thiab diffusion.
4. Kev xaiv xauv lub cuab yeej
5. yeem ncua qia
6. Tsawg torque enables lub compact actuator thiab lub neej voj voog ntev
7. Lub tshuab nqus tsev pov thawj ncej
8. Cov qia txuas ntxiv tuaj yeem xaiv tau
